>> R08ENCPU | MITSUBISHI Programmable logic controller CPU R08ENCPU
R08ENCPU | MITSUBISHI Programmable logic controller CPU R08ENCPU
MITSUBISHI R08ENCPU Manual And Instructions
R08ENCPU datasheetPDF datasheet
MITSUBISHI R08ENCPU Product information and technical parameters：
Brand: MITSUBISHI
Name: Programmable logic controller CPU
Model: R08ENCPU
Operation control mode: stored procedure repeated operation.
Built in IE CC-Link.
Input / output points: 4096 points.
Program capacity: 80K.
Increase the speed of a constant cycle interrupt program.
Perform a minimum interval constant period interrupt program can be shortened to 50 s,
Programmable logic controller can read more high-speed signals.
In addition, the interrupt routine can be set priority, and the interrupt program with high priority is executed when the interrupt processing is interrupted.
Therefore, when the signal is read at a high speed, the program can read the signal from the constant cycle of the conventional input module +CPU module.
Data management using database functions.
Data and production performance data through computer management in the past can be managed by database management of a built-in programmable controller.
Database can be created in the SD memory card, and can use the special instructions to easily add, update, retrieve, delete data.
In addition, the database can be imported and exported through the Unicode text file format,
Share data with spreadsheet software. In particular, can be flexibly used in the production of many varieties of food and beverage production line and other fields,
Effectively carry out the change of formula data and the management of production performance.
