CL2XY16-DTP1C5V | MITSUBISHI Sensor connection type output module CL2XY16-DTP1C5V
MITSUBISHI CL2XY16-DTP1C5V Manual And Instructions
CL2XY16-DTP1C5V datasheetPDF datasheet
MITSUBISHI CL2XY16-DTP1C5V Product information and technical parameters：
Brand: MITSUBISHI
Name: Sensor connection type output module
Model: CL2XY16-DTP1C5V
Input type: DC input, positive common end.
Input points: 8 points.
Input response time: 0.5ms below /1.5ms.
Rated input voltage / current: DC24V/4mA.
Output form: transistor output, leakage type.
Output points: 8 points.
OFF leakage current: 0.1mA.
Output protection function.
Rated load voltage / current: DC24V/0.1A.
External connection: 3 line /2 line type.
Sensor connection type.
Minimum size of industry.
When installing the module can choose to use the DIN guide rail or screw mounting.
3 wire sensor input.
