>> CL1Y2-T1D2S | MITSUBISHI Cable type input module CL1Y2-T1D2S
CL1Y2-T1D2S | MITSUBISHI Cable type input module CL1Y2-T1D2S
MITSUBISHI CL1Y2-T1D2S Manual And Instructions
CL1Y2-T1D2S datasheetPDF datasheet
CL1Y2-T1D2S User's Manual
MITSUBISHI CL1Y2-T1D2S Product information and technical parameters：
Brand: MITSUBISHI
Name: Cable type input module
Model: CL1Y2-T1D2S
Output type: transistor output, drain type.
Output points: 2 points.
OFF leakage current: 0.1mA.
Output protection function: No.
Rated load voltage / current: DC24V/0.1A.
External connection: 2 wire.
Cable type.
Minimum size of industry.
Can be like a cable, placed in the online slot.
The communication cable and the external equipment connecting cable is a type, and the wiring is simple.
Communication side, input and output side with cable (50cm).
