MITSUBISHI CL1XY4-DR1B2 Market price | CL1XY4-DR1B2 Introduction

Close to input / output: 8 DC input or keyboard: 64 DC input, 16 transistor output.
Applicable model: A985/975/970/A960GOT (-B). Control axis: maximum 2 axes.
Operation cycle: 0.88ms.
Interpolation function: linear interpolation (maximum 4 axis), 2 axis arc interpolation.
Color signal: 2 points.
Color detecting set: 4 set.
Only need to use the PLC program can easily achieve synchronous control, cam control, speed and torque (push pressure control) and other advanced motion control CL1XY4-DR1B2
Equipped with standard synchronous encoder and color detection function necessary function.
Can be no procedures for setting. Strong support for MELSOFT.
Can fully apply LD77MH of the old program.
Let motion control more simple. Fiber length: 1 meters.
SSCNET III cables (standard optical fiber used in control cabinet).
Joints for CN1A and CN1B. MITSUBISHI inverter FR-A720 series.
Voltage level: 3 phase 200V.
Frequency converter capacity: 30KW.
Inverter general area of domestic enterprises to occupy more than 80% of the market share,
Production of frequency converter, motor soft starter and other industrial automation control of the manufacturers, the use of heavy-duty design products,
Overload capacity, with super large start and running capacity, improve the automatic detection, protection and control performance,
Can start and control any type of heavy duty motor,
Products have been widely used in metallurgy, mining, paper, chemicals, building materials, machinery, electricity, and construction systems and other industrial transmission areas. Power: 280kw.
Purpose: to suppress the power harmonics.
Connected to the inverter input, can be used to improve the power factor, reduce the input side of the high harmonic current.
According to the motor power used to select AC reactor.
(when the inverter capacity is greater than the motor capacity, is still based on the motor capacity to choose.) Type: MR-J_B series.
Rated output: 0.1KW.
Interface: standard.
Servo system according to the system structure can be divided into open loop servo system, closed loop servo system, semi closed loop system, compound control system.
The closed loop automatic control system with feedback is composed of a position detecting part, a deviation amplifying part, an executing part and a controlled object.
Servo system must have good controllability, high stability and high adaptability.
Note that the control of the signal is good after the disappearance of the signal, can immediately stop the turn;
High stability is the torque with the increase of speed and uniform decline; adaptability is fast, sensitive, and ring state quality is good.
According to the types of servo drives are classified, there are three kinds of electric, hydraulic or electric hydraulic.
If the servo system is divided according to the function, then there is a measuring servo and power servo system;
Analog servo and power servo system; position servo and acceleration servo system.
The electric servo system can be divided into two categories: DC DC servo system and AC AC servo system based on the electrical signals.
AC AC servo system also has two kinds of asynchronous motor servo system and synchronous motor servo system.
CL1XY4-DR1B2 Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=CL1XY4-DR1B2&select=5
