>> CL1XY4-DT1B2 | MITSUBISHI Screw terminal type input and output module CL1XY4-DT1B2
CL1XY4-DT1B2 | MITSUBISHI Screw terminal type input and output module CL1XY4-DT1B2
MITSUBISHI CL1XY4-DT1B2 Manual And Instructions
CL1XY4-DT1B2 datasheetPDF datasheet
CL1XY4-DT1B2 User's Manual
MITSUBISHI CL1XY4-DT1B2 Product information and technical parameters：
Brand: MITSUBISHI
Name: Screw terminal type input and output module
Model: CL1XY4-DT1B2
Input type: DC input, positive public end / negative public end.
Input points: 2 points.
Enter the response time: 1.5ms the following.
Rated input voltage / current: DC24V/4mA.
Output form: transistor output, leakage type.
Output points: 2 points.
OFF leakage current: 0.1mA.
Output protection function: No.
Rated load voltage / current: DC12V/DC24V/0.1A.
External connection: 2 line /2 line type.
Screw terminal table type.
Minimum size of industry.
The connection object at a glance with terminal cover plate.
Input module for public end of positive pole and negative pole.
Terminal table structure capable of connecting with 2 wire type sensor and load in the same condition.
Can be installed along the 6 direction.
...More relevant models >>>>
