Apply PLC:FX2N (up to 3 units), FX3U (up to 3 units).
Applicable PLC:FX2NC (to FX2NC-CNV-IF, up to 1 units), FX3UC (to FX2NC-CNV-IF or FX3UC-1PS-5V, up to 3 units).
The rotation angle detecting unit is controlled by the mechanical cam switch,
The rotation angle is detected by using the special detector, and the rotation position control with high precision is realized.
Using the setting unit, it is easy to realize the setting and monitoring of the action resolution
Q00UJCPU-S8
The detection of rotation angle can be accurate to the high accuracy of 415rpm/0.5 degree or 830rpm/1.0 degree unit.
Built without battery to maintain the EEPROM, the maximum can store 8 kinds of procedures.
The cable that is assembled in the device without the brush can be extended to 100m.
When used alone, the CC-LINK type FX2N-32CCL interface module can be used to connect to the CC-LINK system.
Product composition:
FX2N-1RM: the main body of programmable cam switch (with setting panel).
F2-720RSV: no brush splitter.
FX2N-RS-5CAB: splitter cable (5m).
PLC connecting cable (55mm). Power: 560kw.
Voltage: 400V.
The power factor of the input power factor is up to 0.99 and above (100% load).
Can be connected to multiple inverters, to achieve a common DC bus mode.
Equipped with standard power retrogradation function. Input and output points: 1024 points.
Input / output data points: 1024 points.
Program capacity: 14K.
Basic command processing speed (LD command) s:0.20.
Optical data communication line function (GI cable).
Integral type: the PLC components are installed together or a few pieces of printed circuit board,
And together with the power supply installed in the casing to form a single overall called the host or the basic unit, small, ultra small PLC using this structure.
Modular: PLC is the basic components of a separate module.
Medium and large PLC used this way. Easy maintenance.
Each scanning process. Focus on the input signal sampling. Focus on the output signal to refresh.
Input refresh process. When the input port is closed,
Program in the implementation phase, the input end of a new state, the new state can not be read.
Only when the program is scanned, the new state is read.
A scan cycle is divided into the input sample, the program execution, the output refresh.
The contents of the component image register are changed with the change of the execution of the program.
The length of the scan cycle is determined by the three.
CPU the speed of executing instructions.
Time of instruction.
Instruction count.
Due to the adoption of centralized sampling.
Centralized output mode.
There exist input / output hysteresis phenomena, i.e., the input / output response delay.
User program storage capacity: it is a measure of how much the user application can store the number of indicators.
Usually in words or K words as units. 16 bit binary number is a word,
Every 1024 words are 1K words. PLC to store instructions and data in words.
General logical operation instructions each account for 1 words. Timer / counter,
Shift instruction accounted for 2 words. Data operation instructions for 2~4.
