>> FX2NC-96MT-D/UL | MITSUBISHI PLC FX2NC-96MT-D/UL
FX2NC-96MT-D/UL | MITSUBISHI PLC FX2NC-96MT-D/UL
MITSUBISHI FX2NC-96MT-D/UL Manual And Instructions
FX2NC-96MT-D/UL datasheetPDF datasheet
FX2NC-96MT-D/UL HARDWARE MANUAL
FX2NC-96MT-D/UL PROGRAMMING MANUAL II
FX2NC-96MT-D/UL HARDWARE MANUAL
MITSUBISHI FX2NC-96MT-D/UL Product information and technical parameters：
Brand: MITSUBISHI
Name: PLC
Model: FX2NC-96MT-D/UL
Max input / output points: 96 points.
Power supply voltage: 24VDC.
Input points: 48 points.
Output points: 48 points.
Output type: Transistor (sink).
Power consumption: 14W.
Weight (kg):0.45.
Size (WxHxD) mm:86x90x87.
Taking into account space saving and processing speed.
Connector input and output type compact high performance universal machine.
Compact, scalable input / output.
Can connect analog quantity, communication, positioning, etc..
Rich special extension equipment for FX2N.
By connecting the compact FX2rvc series with the input and output expansion module.
The input and output can be extended to 256 points.
Built in 8000 step RAM memory.
By installing the memory card box, the maximum can be extended to the 16000 step.
Overseas oriented products meet all kinds of international standards.
Use terminal module to replace connector connection or relay terminal row connection,
So as to save the wiring inside the cabinet.
