>> CL1Y4-T1B2 | MITSUBISHI Screw terminal type output module CL1Y4-T1B2
CL1Y4-T1B2 | MITSUBISHI Screw terminal type output module CL1Y4-T1B2
MITSUBISHI CL1Y4-T1B2 Manual And Instructions
CL1Y4-T1B2 datasheetPDF datasheet
CL1Y4-T1B2 User's Manual
MITSUBISHI CL1Y4-T1B2 Product information and technical parameters：
Brand: MITSUBISHI
Name: Screw terminal type output module
Model: CL1Y4-T1B2
Output type: transistor output, drain type.
Output points: 4 points.
OFF leakage current: 0.1mA.
Output protection function: No.
Rated load voltage / current: DC12V/DC24V/0.1A.
External connection: 2 wire.
Screw terminal table type.
Minimum size of industry.
The connection object at a glance with terminal cover plate.
Input module for public end of positive pole and negative pole.
Terminal table structure capable of connecting with 2 wire type sensor and load in the same condition.
Can be installed along the 6 direction.
