>> AJ65SBT-RPT | MITSUBISHI Repeater (T type branch) module AJ65SBT-RPT
AJ65SBT-RPT | MITSUBISHI Repeater (T type branch) module AJ65SBT-RPT
MITSUBISHI AJ65SBT-RPT Manual And Instructions
AJ65SBT-RPT datasheetPDF datasheet
MITSUBISHI AJ65SBT-RPT Product information and technical parameters：
Brand: MITSUBISHI
Name: Repeater (T type branch) module
Model: AJ65SBT-RPT
Description: the maximum number of connections: paragraph 10, can form a T type branch wiring.
Spare 5 products for different purposes.
Thin waterproof type relay hub.
Extension of star type wiring and main line length, waterproof structure.
Spring clip terminal type relay hub.
Star type wiring, length of the main line, spring clamping terminal table type.
Relay appliance (T branch) unit.
Extension of T type branch and trunk length.
Relay unit in light.
In the presence of interference in the environment of the wiring, the length of the trunk line.
Relay unit in space light.
Communication between linear moving bodies.
