AJ65BTS-RPH | MITSUBISHI Spring clip terminal type repeater module AJ65BTS-RPH
MITSUBISHI AJ65BTS-RPH Manual And Instructions
AJ65BTS-RPH datasheetPDF datasheet
MITSUBISHI AJ65BTS-RPH Product information and technical parameters：
Brand: MITSUBISHI
Name: Spring clip terminal type repeater module
Model: AJ65BTS-RPH
Description: can form up to 8 star wiring, and suitable for transmission speed of the length of the line distribution, spring clip terminal type.
Spare 5 products for different purposes.
Thin waterproof type relay hub.
Extension of star type wiring and main line length, waterproof structure.
Spring clip terminal type relay hub.
Star type wiring, length of the main line, spring clamping terminal table type.
Relay appliance (T branch) unit.
Extension of T type branch and trunk length.
Relay unit in light.
In the presence of interference in the environment of the wiring, the length of the trunk line.
Relay unit in space light.
Communication between linear moving bodies.
...More relevant models >>>>
