MITSUBISHI FA-TB8XY3 Market price | FA-TB8XY3 Introduction

Input type: DC input, positive common end.
Input points: 8 points.
Enter the response time: 1.5ms the following.
Rated input voltage / current: DC24V/7mA.
Output form: transistor output, leakage type.
Output points: 8 points.
OFF leakage current: 0.25mA.
Output protection function.
Rated load voltage / current: DC24V/0.5A.
External connection: 3 line /2 line type.
According to the external connection mode and the external equipment input and output specifications,
Choose from a rich product lineup FA-TB8XY3
Finger protection through the upper part of the terminal,
The human body will not be exposed to live parts,
Therefore, the terminal station type remote I/O module can be directly mounted to the machine tool. "Transistor output.
Axis of control: 4.
Control unit: mm, inch, degree, pulse.
Location data: 600 data / axis.
Module backup function: the positioning data, module start data saved to the flash ROM (no battery).
Boot time (operation cycle 0.444ms, 1 axes): 0.3ms.
Maximum output pulse: 200000pulse/s.
The maximum distance between servo system: 2m.
External wiring connection: 40 pin connector two.
Straight line interpolation: 2 axis, 3 axis, 4 axis.
Arc interpolation: 2 axes.
Easy positioning control
The positioning module uses the position control and speed control, which is set by the engineering software.
In the position control and speed control is also equipped with an increase in the "conditional judgment" after the implementation of the specified positioning data and other advanced positioning control functions.
For example, in the automobile door sealing process, the need to carry out high precision positioning control,
In order to applying sealant on the sealing part of the door.
Therefore, it is necessary to track the precise trajectory through the straight line and the arc, and implement the high precision interpolation control.
The positioning module includes a transistor output type and a differential driver output type 2, which can be selected according to the connection of the drive module.
When selecting the output type of the differential driver, the high speed pulse of the highest 5Mpulse/s can be output and the longest distance connection of the 10m is carried out.
Position control and speed control can be carried out by the positioning module.
In addition to the previous linear interpolation function, arc interpolation function, but also a new spiral line interpolation function,
Can be used for milling and other complex control purposes. "
