L61P-CM | MITSUBISHI Power module L61P-CM
MITSUBISHI L61P-CM Manual And Instructions
L61P-CM datasheetPDF datasheet
MITSUBISHI L61P-CM Product information and technical parameters：
Brand: MITSUBISHI
Name: Power module
Model: L61P-CM
Input power: AC100-240V.
Output: DC5V, 5A.
Power supply module can be directly pasted on the printed circuit board of the power supply,
The device is characterized in that a special integrated circuit (ASIC), a digital signal processor (DSP), a microprocessor, a memory, a field programmable gate array (FPGA), and other digital or analog loads are provided.
In general, this type of module is called the load point (POL) power supply system or the use of point power supply system (PUPS).
Because of the advantages of the modular structure,
The module power supply is widely used in switching devices, access devices, mobile communications, microwave communications and optical transmission, routers and other communication fields and automotive electronics, aerospace, etc..
