>> A1SY71 | MITSUBISHI output module A1SY71
A1SY71 | MITSUBISHI output module A1SY71
MITSUBISHI A1SY71 Manual And Instructions
A1SY71 datasheetPDF datasheet
A1SY71 User's Manual
MITSUBISHI A1SY71 Product information and technical parameters：
Brand: MITSUBISHI
Name: output module
Model: A1SY71
Output type: transistor drain.
Output points: 32 points.
Load voltage: DC5/12.
Load current: 0.016A.
Connection: FCN connector.
Common public end points: 32.
Switching value, also known as logic, refers to only two values, 0 or 1, ON or OFF.
It is the most common control, it is the advantage of PLC control,
Is also the most basic application of PLC.
Switch volume control is designed to,
According to the current input combination of the switch quantity and the history of the input sequence,
So that PLC generates the corresponding switching output,
In order to make the system work in a certain order.
So, sometimes also known as the order control.
And sequential control is divided into manual, semi-automatic or automatic.
And the control principle is decentralized, centralized and hybrid control three.
