A0J2CPU-DC24 | MITSUBISHI CPU unit A0J2CPU-DC24
MITSUBISHI A0J2CPU-DC24 Manual And Instructions
A0J2CPU-DC24 datasheetPDF datasheet
A0J2CPU-DC24 Programming Manual
A0J2CPU-DC24 Common InstructionsProgramming Manual
A0J2CPU-DC24 Dedicated InstructionsProgramming Manual
A0J2CPU-DC24 FundamentalsProgramming Manual
A0J2CPU-DC24 Programming Manual
MITSUBISHI A0J2CPU-DC24 Product information and technical parameters：
Brand: MITSUBISHI
Name: CPU unit
Model: A0J2CPU-DC24
Input and output points: 480 points.
Program capacity: 7K step.
Basic command processing speed: 4.4 ~ 5.6us.
Power supply: input DC5V output 2A DC24V/.
Modular: PLC is the basic components of a separate module.
Medium and large PLC used this way. Easy maintenance.
User program storage capacity: it is a measure of how much the user application can store the number of indicators.
Usually in words or K words as units. 16 bit binary number is a word,
Every 1024 words are 1K words. PLC to store instructions and data in words.
General logical operation instructions each account for 1 words. Timer / counter,
Shift instruction accounted for 2 words. Data operation instructions for 2~4.
Relay output interface circuit of PLC
Working process: when the internal circuit output digital signal 1,
There is a current flowing through, the relay coil has a current, and then the normally open contact is closed,
Provide load current and voltage.
When the internal circuit outputs a digital signal 0, there is no current flowing through it,
The relay coil does not have a current, and the normally open contact is broken off,
A current or voltage that is disconnected from the load.
It is through the output interface circuit to the internal digital circuit into a signal to make the load action or not action.
