MITSUBISHI FX3S-14MT/DSS Market price | FX3S-14MT/DSS Introduction

Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 0.5kw.
Rated speed: 3000rpm.
With the brake: without.
Shaft end: straight shaft.
When the AC servo motor has no control voltage, only the pulsating magnetic field generated by the excitation winding is generated in the stator, and the rotor is still not moving.
When the control voltage is controlled, a rotating magnetic field is generated in the stator, and the rotor rotates in the direction of the rotating magnetic field,
In the case of constant load, the speed of the motor varies with the size of the control voltage,
When the phase of the control voltage is reversed, the servo motor will reverse FX3S-14MT/DSSCable length: 2.5m.
For motion controller CPU (A series, the main base system) and the connection between GOT.
Applicable models: GT16, GT15, GT11. "Transistor output.
Axis of control: 2.
Control unit: mm, inch, degree, pulse.
Location data: 600 data / axis.
Module backup function: the positioning data, module start data saved to the flash ROM (no battery).
Boot time (operation cycle 0.444ms, 1 axes): 0.3ms.
Maximum output pulse: 200000pulse/s.
The maximum distance between servo system: 2m.
External wiring connection mode: 40 pin connector.
Linear interpolation: 2 axes.
Arc interpolation: 2 axes.
Positioning module
Positioning module can be the highest 5Mpulse/s*1 of the high-speed pulse output up to 4 axis control.
A pulse train input servo amplifier, a step motor driver, etc., which can be connected with a transistor (open collector) or a differential driver input interface, is a universal driver module.
The positioning module includes a transistor output type and a differential driver output type 2, which can be selected according to the connection of the drive module.
When selecting the output type of the differential driver, the high speed pulse of the highest 5Mpulse/s can be output and the longest distance connection of the 10m is carried out.
Position control and speed control can be carried out by the positioning module.
In addition to the previous linear interpolation function, arc interpolation function, but also a new spiral line interpolation function,
Can be used for milling and other complex control purposes. "
FX3S-14MT/DSS Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=FX3S-14MT/DSS&select=5
