MITSUBISHI AJ65SBT-CLB Market price | AJ65SBT-CLB Introduction

Country: JAPAN
Name: CC-LINK/LT bridge module
Model: AJ65SBT-CLB
Market price: U.S.$ 728.81
(The following are the market open price not sales price!)
MITSUBISHI AJ65SBT-CLB
MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 22.0kw.
Interface type: CC-Link communication type (built-in positioning function).
Power specification: three phase AC200V.
Positioning operation by setting position and rotational speed data in the positioning table and receiving the start signal from the main controller.
The setting of the position and speed of the positioning table, as well as the start and stop operation can be completed through CC-Link communication AJ65SBT-CLB
By using the MR-J3-D01 extension IO unit, the DI/O instruction can be used to select and locate the table.
(CC-Link can not be used for MR-J3-D01 communications).
With built-in positioning function of the servo amplifier, can be set through the CC-Link communications and speed data. (corresponding to the CC-Link version: Ver.1.10)
Can be achieved through the CC-Link communications to start, stop and monitoring and other operations.
Serial communication reduce wiring.
Distributed servo control system can be built by CC-Link communication.
The parameters of unit MR-PRU03 (optional) the parameter setting, operation and monitoring more convenient.
The servo amplifier can be used for speed control operation.
When the two stations are occupied, the speed can be set directly by the remote register. "Transistor output.
Axis of control: 2.
Control unit: mm, inch, degree, pulse.
Location data: 600 data / axis.
Module backup function: the positioning data, module start data saved to the flash ROM (no battery).
Boot time (operation cycle 0.444ms, 1 axes): 0.3ms.
Maximum output pulse: 200000pulse/s.
The maximum distance between servo system: 2m.
External wiring connection mode: 40 pin connector.
Linear interpolation: 2 axes.
Arc interpolation: 2 axes.
Positioning module
Positioning module can be the highest 5Mpulse/s*1 of the high-speed pulse output up to 4 axis control.
A pulse train input servo amplifier, a step motor driver, etc., which can be connected with a transistor (open collector) or a differential driver input interface, is a universal driver module.
The positioning module includes a transistor output type and a differential driver output type 2, which can be selected according to the connection of the drive module.
When selecting the output type of the differential driver, the high speed pulse of the highest 5Mpulse/s can be output and the longest distance connection of the 10m is carried out.
Position control and speed control can be carried out by the positioning module.
In addition to the previous linear interpolation function, arc interpolation function, but also a new spiral line interpolation function,
Can be used for milling and other complex control purposes. "
