>> LY42PT1P-CM | MITSUBISHI Transistor output module (source) LY42PT1P-CM
LY42PT1P-CM | MITSUBISHI Transistor output module (source) LY42PT1P-CM
MITSUBISHI LY42PT1P-CM Manual And Instructions
LY42PT1P-CM datasheetPDF datasheet
MITSUBISHI LY42PT1P-CM Product information and technical parameters：
Brand: MITSUBISHI
Name: Transistor output module (source)
Model: LY42PT1P-CM
Output points: 64 points.
Output form: source type.
Rated output voltage: DC12 ~ 24V.
Max load current: 0.1A/1 point.
Protection function: have.
Common way: 32 point / public end.
Input / output occupied points: 64 points (I/O distribution: output 64 points).
External wiring connection: 40 pin connector two.
The switch input and output module is a device which can collect the input / output of the switch signal,
Digital I/O modules are often called.
The switch signal is collected to the computer or the computer to send the relevant instructions through the RS-485 bus to control the switch of the switch,
Can also be carried out through the RS-485 bus communication,
Remote control switch.
Communication protocol is a standard Modbus protocol or custom protocol.
