>> HF-SP702B | MITSUBISHI Medium inertia power servo motor HF-SP702B
HF-SP702B | MITSUBISHI Medium inertia power servo motor HF-SP702B
MITSUBISHI HF-SP702B Manual And Instructions
HF-SP702B datasheetPDF datasheet
MITSUBISHI HF-SP702B Product information and technical parameters：
Brand: MITSUBISHI
Name: Medium inertia power servo motor
Model: HF-SP702B
Servo motor series: medium inertia, medium power.
Rated output: 7.0kw.
Rated speed: 2000r/min.
Electromagnetic brake: with.
Shaft end specification: Standard (straight axis).
Characteristics: medium inertia has two types of low speed and high speed, suitable for different applications.
IP level: IP67.
Application example:
1, material handling system.
2, industrial robots.
3, X-Y working table.
The protection level of the HF-SP/HF-JP series servo motor is IP67 (except the shaft part).
Motor capacity selection soft (MRZJW3-MOTSZ111E)
Friendly interface design, only in the mechanical description window input constant and operation mode can choose the best servo amplifier,
The servo motor and the regenerative braking options, but also in the selection window in the selection of linear servo motor and direct drive motor.
Characteristic
(1) 10 typical mechanical transmission structure can be used to choose
(2) user defined operating modes (location and speed control)
(3) in the selection process, the feed speed and torque can be displayed in a graphical format.
(4) the calculation process can be displayed
Can easily calculate the power of the servo motor free software!
