HC-SFS203 | MITSUBISHI Medium inertia power motor HC-SFS203

Motor series: medium inertia, medium power.
Rated output power: 2.0kw.
Rated speed: 2000r/min.
Whether to take the brake: No.
Shaft end: Standard (straight).
Power supply: 400V type.
Protection level: IP65 (IP67).
Features: medium inertia from low speed to high speed three modes for selection, suitable for different applications MITSUBISHI HC-SFS203.
Application examples: transmission machinery, robots, X-Y working platform HC-SFS203
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring. Type: general purpose AC servo amplifier MR-E series.
Rated output: 0 MITSUBISHI HC-SFS203. 1kw.
Interface type: general purpose pulse interface.
KH003 special mark for Super MR-E.
High performance and easy to operate, reduce work load.
Enhanced system cost performance.
High performance, high precision positioning (servo motor encoder resolution: 131072).
High response.
Suppression of vibration by adaptive vibration suppression control.
Using personal computer and servo setup software to optimize tuning MITSUBISHI HC-SFS203.
Has 2 types of interfaces:
Position control and speed control with pulse train interface.
The analog input interface is used for speed control and torque control. Cable length: 1.0M.
Amplifier CC-Link interface unit cable.
For MR-J2S-11KA (4) MR-J2S-22KA to (4). Type: HA-SH series.
Rated output: 0.5KW.
Rated speed: 1000r/min.
Electromagnetic brake: there.
From the vector control technology of AC servo motor, it has become more and more popular.
From the point of view of the real time operating system, it is just a function module that needs to be processed in real time.
Due to the multi function of the controller, intelligent requirements, a large number of signal processing,
Establishment and operation of various mathematical models of adaptiive control,
Network communications and other functional modules will be in the real-time operation of the unified scheduling and management of the system to get the correct and reliable operation HC-SFS203.
Therefore, the next generation of servo ddrive controller will be a collection of various modern control technology of the crystallization,
Instead of the traditional sense of power amplifier HC-SFS203.
