>> HC-RFS503 | MITSUBISHI Ultra low inertia medium power motor HC-RFS503
HC-RFS503 | MITSUBISHI Ultra low inertia medium power motor HC-RFS503
MITSUBISHI HC-RFS503 Manual And Instructions
HC-RFS503 datasheetPDF datasheet
MITSUBISHI HC-RFS503 Product information and technical parameters：
Brand: MITSUBISHI
Name: Ultra low inertia medium power motor
Model: HC-RFS503
Motor series: super low inertia, medium power.
Rated output power: 5.0kw.
Rated speed: 3000r/min.
Whether to take the brake: No.
Shaft end: Standard (straight).
Protection level: IP65 (IP67).
Features: ultra low inertia is suitable for high frequency operation.
Application example: ultra high frequency transmission machinery.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring.
