MITSUBISHI HC-RFS103B Product information and technical parameters：
Brand: MITSUBISHI
Name: Ultra low inertia medium power motor
Model: HC-RFS103B
Motor series: super low inertia, medium power.
Rated output power: 1.0kw.
Rated speed: 3000r/min.
Whether to bring the brakes: with.
Shaft end: Standard (straight).
Protection level: IP65 (IP67).
Features: ultra low inertia is suitable for high frequency operation.
Application example: ultra high frequency transmission machinery.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring.

Drive: MR-H_AN series.
Rated output: 0.6KW.
Universal AC servo.
Servo driver (drives servo) also known as the "servo controller", "servo amplifier",
Is a kind of controller used to control the servo motor. Its function is similar to that of the frequency converter,
Belongs to a part of the servo system, which is mainly used in high precision positioning system MITSUBISHI HC-RFS103B.
In general, the servo motor is controlled by position, speed and torque in three ways,
To achieve high precision positioning of the transmission system, the current transmission technology is the high-end products HC-RFS103B
Servo drive is an important part of modern motion control,
Is widely used in industrial robots and CNC machining centers and other automation equipment MITSUBISHI HC-RFS103B.
In particular, it has become a hot research topic in the field of servo drives for the control of AC permanent magnet synchronous motor.
Current, speed and position 3 closed loop control algorithm based on vector control is widely used in AC servo drive system.
The speed closed-loop design of the algorithm is reasonable or not, for the entire servo control system,
Especially the speed control performance plays a key role MITSUBISHI HC-RFS103B. Servo motor series: low inertia, medium / high power.
Rated output: 9.0kw.
Rated speed: 3000r/min.
Electromagnetic brake: with.
Shaft end specification: Standard (straight axis).
Features: low inertia for high speed / acceleration and deceleration operation occasions.
IP level: IP67.
Application example:
1, food processing machinery.
2, printing machine.
3, injection molding machine (11KW, 15KW).
4, large press machine (11KW, 15KW).
The protection level of the HF-SP/HF-JP series servo motor is IP67 (except the shaft part).
Low inertia of the power servo motor (0.5kW ~ 9kW), the maximum speed: 6000r/min (rated speed: 3000r/min),
Suitable for high frequency positioning and acceleration / deceleration operations, especially for food processing machines and printing machines.
Low inertia, high power, no cooling fan servo motor (11kW and 15kW), maximum speed: 3000r/min (rated speed: 1500r/min).
The motor structure is more compact due to the adoption of the non cooling fan design, and the conneection is reduced by using the power source connector HC-RFS103B.
(compared with the HF-LP series servo motor with the same power, the volume is reduced by about 46%, and the weight is reduced by about 34%,
Suitable for high frequency positioning annd acceleration / deceleration operations, especially for injection molding machines and large presses HC-RFS103B.
HF-JP703 (4) /903 (4) maximum speed: 5000r/min.
