>> GT1265-VNBA | MITSUBISHI 8.4 Inch Touch Screen GT1265-VNBA
GT1265-VNBA | MITSUBISHI 8.4 Inch Touch Screen GT1265-VNBA
MITSUBISHI GT1265-VNBA Manual And Instructions
GT1265-VNBA datasheetPDF datasheet
GT1265-VNBA MES Interface Function Manual
GT1265-VNBA Gateway Functions Manual
GT1265-VNBA Extended/Option Functions Manual
GT1265-VNBA Mitsubishi plc ConnectionsConnection Manual
GT1265-VNBA Connection Manual
MITSUBISHI GT1265-VNBA Product information and technical parameters：
Brand: MITSUBISHI
Name: 8.4 Inch Touch Screen
Model: GT1265-VNBA
Series introduction: with a variety of integrated functions and communication interface, and a larger volume of the basic model.
Screen size: 8.4 inches.
Display color: 256 color or more color.
Mounting type: panel mounting type.
Resolution: VGA (640 x 480).
Display device: TFT color.
Host frame color: black.
Power type: AC100~240V.
Communication interface: with built-in RS-422.
With a variety of integrated functions and communication interface and a larger volume of the basic model.
User storage capacity: 6MB.
Device USB interface.
Standard Ethernet, RS-422/485 and RS-232 interface.
Analog touch panel.
From the technical principle to distinguish the touch screen, can be divided into five basic types: vector pressure sensor touch screen, resistive touch screen, capacitive touch screen technology, infrared touch screen technology, surface acoustic wave touch screen technology.
Vector pressure sensing technology touch screen has been withdrawn from the stage of history;
Infrared touch screen technology and low price, but the frame is fragile, easy to produce light interference and surface distortion;
The design of capacitive touch screen is reasonable, but it is difficult to solve the problem of image distortion;
The touch screen positioning resistor technology is accurate, but its price is high, and fear of vulnerability scratch;
The surface acoustic wave touch screen solves various defects of the touch screen in the past,
Clear and not easy to be damaged, suitable for various occasions,
The disadvantage is that the screen surface if there is water droplets and dust will make the touch screen become slow, or even work.
