>> FX5-16EYT/ESS | MITSUBISHI output module FX5-16EYT/ESS
FX5-16EYT/ESS | MITSUBISHI output module FX5-16EYT/ESS
MITSUBISHI FX5-16EYT/ESS Manual And Instructions
FX5-16EYT/ESS datasheetPDF datasheet
MITSUBISHI FX5-16EYT/ESS Product information and technical parameters：
Brand: MITSUBISHI
Name: output module
Model: FX5-16EYT/ESS
Input / output type: transistor output (source).
Output points: 16 points.
DC5V internal consumption current: 100mA.
DC24V internal consumption current: 125mA.
In order to extend the input output of the device.
Also has a built-in power supply products.
The maximum number of points for the input and output is 256.
Expansion module: up to 16 units (in addition to the power expansion module)
The total number of CC-Link, AnyWireASLINK, and Bitty series of remote I/O is 512 points.
