AJ65SBTB1-16D | MITSUBISHI Input module AJ65SBTB1-16D
MITSUBISHI AJ65SBTB1-16D Manual And Instructions
AJ65SBTB1-16D datasheetPDF datasheet
MITSUBISHI AJ65SBTB1-16D Product information and technical parameters：
Brand: MITSUBISHI
Name: Input module
Model: AJ65SBTB1-16D
Input type: DC input, positive public end / negative public end.
Input points: 16 points.
Enter the response time: 1.5ms the following.
Rated input voltage / current: DC24V/7mA.
External connection: 1 wire.
According to the external connection mode and the external equipment input and output specifications,
Choose from a rich product lineup.
Finger protection through the upper part of the terminal,
The human body will not be exposed to live parts,
Therefore, the terminal station type remote I/O module can be directly mounted to the machine tool.
