Operation control mode: stored procedure repeated operation.
Input / output points: 4096 points.
Program capacity: 160K step.
Multi CPU system for high precision motion control
The high speed control can be realized by executing the parallel control program and the parallel processing of multi CPU high speed communication.
The communication cycle between multi CPU has been synchronized with the motion control time, which can reduce the redundant control time
GT15-60ATT-77
After installing the 3 motion CPU modules, the maximum of 96 axes can be used for servo control.
Program capacity of up to 1200K.
Multi CPU system for high precision motion control.
The built-in CPU module support 2 Gigabit Network port.
Database functions to facilitate data management.
Extended SRAM card with built-in security function.
Can be carried out a variety of motion control (position, speed, torque, advanced synchronous control, etc.).
In line with the international safety standards (13849-1 PL e ISO, IEC 61508 SIL 3) security CPU.
The most suitable for C/C++ language programming from the computer / computer environment for transplantation. Motor series: medium inertia, medium power.
Rated output power: 5.0kw.
Rated speed: 2000r/min.
Whether to take the brake: No.
Shaft keyway: (open slot).
Protection level: IP65 (IP67).
Features: medium inertia from low speed to high speed three modes for selection, suitable for different applications.
Application examples: transmission machinery, robots, X-Y working platform.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring.
Type: HC-PQ type.
Output power: 0.4kw.
Rated speed: 3000r/min.
Electromagnetic brake: No.
Key axis: straight shaft.
Motor aspects: the material, structure and processing technology of the servo motor is much higher than that of AC motor,
That is when the driver output current, voltage, frequency change is fast power supply,
The servo motor can change according to the change of the response of the power supply,
Response characteristics and anti overload capacity is much higher than the AC motor drive,
Motor aspects of the serious differences between the two are fundamentally different performance.
That is not the inverter output can not change so fast power signal,
But the motor itself can not react,
So in the frequency of the internal algorithm set to protect the motor to do the corresponding overload.
Of course, even without the ability to set the output of the inverter is limited,
Some of the excellent performance of the inverter can be directly driven servo motor.
GT15-60ATT-77 Operation manual / Instructions / Catalog download link:
/searchDownload.html?Search=GT15-60ATT-77&select=5
