MITSUBISHI AX80Y80C Market price | AX80Y80C Introduction

Power supply: 120mA DC5V (PLC internal power supply), 160mA DC24V.
Analog output points: 4 points.
Voltage output: DC-10~10V.
Current output: DC0~20mA, 4~20mA.
Weight: 0.2kg.
Dimensions: 55 x 90 x 87.
The resolution of the 4 channel is 15bit binary + symbol 1bit (voltage),
High precision analog output module of 15bit binary (current).
Each channel voltage output (DC-10~10V) or current output (DC0~20mA, DC4~20mA) can be specified,
Mixed use AX80Y80C
With the form of the output and the upper and lower values and other rich features.
FX3UC-4AD can connect FX3GA/FX3G, FX3GE, FX3U series.
When connecting to FX3UC or FX3GC, you need FX2NC-CNV-IF or FX3UC-IPS-5V. MITSUBISHI inverter series: FR-A820.
Voltage level: three phase 200V.
Power: 15kw.
SLD converter rated current: 77A.
Structure and function: Standard model.
Type: CA.
Substrate coating: have.
Parameters can be selected by 4 different rated current and different overload rating (SLD (ultra light load) rated, LD (light load) rating, ND (general load) rating, HD (weight).
Type load) for selection.
You can choose the most suitable frequency converter for use; and by selecting a transducer with a SLD or LD rated level,
Be able to reduce the size of the device (compared with the FR-A700 series, to reduce the volume of equipment).
For applications that require high torque at low speeds, the HD rating is the most suitable.
The controller is used to control and monitor the frequency converter through the network.
Standard corresponding RS-485 communication (MITSUBISHI converter protocol, Modbus-RTU protocol) data transmission speed up to 115200bps. Drive unit.
MITSUBISHI universal AC servo amplifier MELSERVO-J4 series.
Rated output: 37kw.
Interface: SSCNET III /H.
Power supply: three phase AC200V.
Support position control, speed control, torque control.
Position control to follow the position instructions.
When the control is inserted, the position control is performed.
Speed control follows the speed command to control the speed within a certain range.
Torque control to follow the torque command to control the stable torque.
Function of switching amplitude. The increase in the process of switching and stopping,
And in the operation of the use of the switching signal, switching growth.
AX80Y80C Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=AX80Y80C&select=5
